CAT6 – DPA81051

HDPE Insulated UTP, FTP, STP and External rated

CCTV, Network Solutions, Access Control, Data Transmission.

Specification Sheet:
  Click to download specifications


2 Core 65/.16 (1.3mm sq nom.) T.C.W. V75 P.V.C insulated.
HBZRH-80FZW Low smoke, Low Halogen P.V.C. sheathed.
Tysonic Speaker Flex.
Oxygen-free copper. RoHS compliant.


Conductor: 65 strands of 0.16 mm Annealed Copper to AS/NZS1125 drawn from Class 102 copper to AS/NZS1574.
Max. D.C. resistance at 20C : 13.7 ohms / km.

Insulation: Coloured V75 PVC to AS/NZS3808.
Nominal Diameter: 2.1 mm.
Nom. Wall Thickness: 0.60 mm.

Lay Up: 2 Cores.
1. Red
2. Black

Sheath: Coloured P.V.C. type HBZRH-80FZW.
Nominal Diameter: 6.3 mm.
Nom. Wall Thickness: 1.0 mm.

Identification: Printed at max 1000mm spacings – Cable to be meter marked, i.e every 1 meter – TYCAB NZ Y.O.M. – 1.3mm² 16AWG 2 CORE 100V LINE SPEAKER CABLE M|M
