1 x 4mm² – H1Z2Z2-K1X4

EN50618/IEC62930 131
XLPO insulated 1.5kV DC Only

Recreational Vehicle and Solar Panel Installations.

Specification Sheet:
  Click to download specifications

56/.3 (4 mmsq). Tinned, Halogen-free insulated & Halogen-free
Sheathed, double insulated single core.
Certified to EN50618/IEC62930. TUV
Certificate no: R50163227
1.5Kv dc -40c to 90c


Conductor: 56 strands of 0.3mm nom TINNED Annealed Copper to AS/NZS 1125 Class 5.
Max. D.C. resistance at 20C : 5.09 ohms / km.

Insulation: Black Low smoke halogen flame retardant XLPO.
Nom. Wall Thickness: 0.65 mm.

Sheath: Black Low smoke halogen flame retardant XLPO.
Nominal Dimensions: 6.1 mm.
Nom. Wall Thickness: 0.6 mm.

Identification: Printed on sheath in contrasting colour – TYSOLA XLPO insulated TUV CERTIFIED 4MM2 1.5kV DC UV STABLE DC USE ONLY – DO NOT DISCONNECT UNDER LOAD 001M >I<
