2C + E x 2.5mm² – BELS37067

HFI-90-TP Insulated 450/750V

Power and Lighting applications up to 450/750V

Specification Sheet:
  Click to download specifications

2 Core Flat Twin and Earth 7/.67 ( 2.5 mm sq nom.). P.A.C.W.
HFI-90-TP insulated and HFS-90-TP sheathed. Low Smoke Zero Halogen.
Building Cable 450/750 Volt to AS5000.2.


Conductor:7 strands of 0.67 mm Plain Annealed Copper to AS1125 drawn from Class 110A copper to AS1574.
Max. D.C. resistance at 20C : 7.4 ohms / km.

Insulation: Coloured HFI-90-TP. to AS3808.
Nominal Diameter: 3.4mm.
Nom. Wall Thickness: 0.7mm.

Core Colours:
1. Red
2. Green / Yellow
3. Black
Laid parallel.

Sheath: Coloured HFS-90-TP to AS3808. Flat configuration.
Nominal Dimensions : 5.5 x 12.2 mm.
Nom. Wall Thickness: 1.0 mm.

Identification: Printed on the sheath – TYCAB 2008 ELECTRIC CABLE HFI-90-TP 450/750V * 2.5MMSQ T&E.
